Hygienic Powder Butterfly Valve A valve designed for powder processing with high hygiene standards.
The hygienic powder butterfly valve is an evolution of the traditional butterfly valve, offering a hygienic, simple design with low maintenance costs. It consists of two precision-machined body halves, a butterfly disc, and an inflatable seal. It is designed to intercept the flow of bulk solid products (powders, granules, etc.). Its fundamental design makes it particularly suitable for applications requiring high hygiene levels, ease of use, and stringent cleaning and maintenance requirements. The inflatable seal ensures excellent tightness and prevents the dispersion of elastomer particles into the product.
· Superior reliability and long service life
· Double eccentric design for excellent vacuum and pressure resistance
· Dead-leg free, hygienic design
· cGMP compliant with CIP and SIP capabilities
· Large flow area, low flow resistance, ensuring unobstructed product discharge
· Modular system
· Various sealing materials available
· Special maintenance-free bearings
· Wide range of bulk densities
· Solvent-wet bulk materials or free-flowing
· Crystalline and abrasive particles
· Hard and soft granules
· Wide particle size range
· Inlet/Outlet valves for vacuum dryers
· Inlet/Outlet valves for powder mixers
· Discharge valves for centrifuges
· Inlet/Outlet valves for reactors
Valve Size | DN100-DN400 (4”-16”) |
Flange Standard | DIN HG20592, Tri-Clamp (3A BPE) |
Materials | 316L, 2205, HC276, or customer-specified |
Inflatable Seal | EPDM, FKM, FFKM |
Operating Temp. | -10°C to 135°C |
Operating Pressure | -1 to +6 bar |
Surface Finish | Product contact ≤ Ra0.8; Non-contact ≤ Ra1.6 |
